Hikvision DS–2CD2020F-I 2MP 1080P Compact IP Night Vision Outdoor Bullet Camera
PRODUCT SPECIFICATIONS
| Brand | Hikvision |
| Operating Temperature |
-30 to 60 deg C (-22 to 140 deg F) |
| Video Compression |
H.264/MJPEG |
| Network protocols |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour |
| Video Bit Rate |
32 Kbps to 8 Mbps |
| Shutter Time |
1/3 to 1/100,000 s |
| Weather Proof rating |
IP67 |
| Dimensions |
70x157x62 mm |
| Frame rate |
50 Hz: 25fps (1920×1080), 25fps (1280×960), 25fps (1280×720) 60 Hz: 30fps (1920×1080), 30fps (1280×960), 30fps (1280×720) |
| Weight |
500 g |
| Day & Night |
IR cut filter with auto switch |
| Lens Mount |
M12 |
| Operating Humidity |
95% or less (non-condensing) |
| Dual Steam |
Yes |
| Package Contents |
1 IP Bullet Camera, Product Manual, 1 CD, Gypsum Screws |
| Image Resolution |
1920x1080p (Max) |
| Minimum Illumination |
0.01 Lux at (F1.2, AGC ON), 0 Lux with IR 0.028 Lux at (F2.0, AGC ON), 0 Lux with IR |
| Network |
Network Storage: NAS (Support NFS,SMB/CIFS) Security: One-key reset, flash-prevention, dual streams, heartbeat, mirror, password protection, privacy mask, Watermark, IP address filtering, Anonymous access System Compatibility: ONVIF, PSIA, CGI, ISAPI |
| Image Sensor |
1/2.8 inch Progressive Scan CMOS |
| Lens |
4 mm at F2.0, Angle of view: 85 deg (6 mm optional) |
| IR Distance |
30 m |
| Power Consumption |
5.8 W (Max) |
| Interface |
Communication Interface: 1 RJ45 10M / 100M Ethernet interface On-board storage: Built-in Micro SD/SDHC/SDXC slot, up to 128 GB Reset Button: Yes |
| Item Code |
DS-2CD2020F-I |
