Merida EBIG Trail 500 MTB Hardtail 2017 – Electric Bike
Product description
Ride further with less effort. The Merida eBig Trail is a hardtail MTB that gives you an electric bike boost for easier riding.
The lightweight Technoformed 6061 aluminium alloy frame features aggressive trail geometry for confident handling on the rough. Unlike many other ebikes the chainstays are nice and short for nimble handling on technical trails.
Boosting your natural pedalling power is the Shimano 250w STePS motor that is combined with a 500Wh battery pack to give you long lasting performance. There are three power modes, along with a walk assist button, so you can adjust the power output, managing the battery capacity to last the whole ride. The handlebar mounted display unit allows you to monitor the battery and select the power modes on the fly.
Ideal for hardtail mountain biking, the 650b wheels are shod with 2.8” Maxxis plus sized tyres which offer extra grip in the corners as well as more ‘float’, soaking up the lumps and bumps on the trail for a smoother ride.
Up front the Suntour Auron fork gives you 130mm of plush suspension travel to tame the trail. The Shimano Deore 1×10 speed drivetrain offers secure shifting with a wide range of gears so you can ride every trail with ease. When the trail points downhill the Shimano Deore hydraulic disc brakes offer powerful stopping control thanks to the oversized disc rotors.
Enjoy more trails on every ride with the Merida eBig Trail 500.
Please Note: The bike no longer comes with the Fox fork as pictured. This is now a Suntour Auron.
Key Features:
- Lightweight Technoformed 6061 aluminium frame
- Shimano STePS E8000 electric system gives extra power to your pedalling
- Shimano Deore 1×10 speed drivetrain for reliable shifting
- Suntour Auron fork for 130mm of plush suspension travel
- Lifetime frame warranty
- Sizes: Small, Medium, Large
- Colour: Green
Drive Information:
- Motor: 250W Shimano STePS E8000
- Battery: 500Wh Shimano STePS 8010
- User interface/remote: Control Switch Unit and Display
- Power Modes: Boost, Trail, Eco and Walk Assist
The Merida eBIG Trail 500 MTB Hardtail 2017 Features are:
Frame: Technoformed 6061 aluminium frame with aggressive trail geometry – STePS 8000 motor allows for short chain stays delivering agility
Fork: Suntour Auron 130mm
Bars: Merida Expert 760mm wide 35mm rise
Stem: Merida Expert 35mm extension
Speed: 10
Rear Mech: Shimano Deore Shadow+
Shifters Shimano Deore
Chainset: Shimano E8000 CRE80-B 34
Bottom Bracket: Integrated
Cassette: Shimano HG50, 10 speed, 11-36
Chain: KMC X10
Front Brake: Shimano M615 hydraulic disc brakes 203mm rotors
Rear Brake: Shimano M615 hydraulic disc brakes 180mm rotors
Rims: Merida Expert TP
Front Hub: Shimano Deore boost centrelock
Rear Hub: Shimano Deore boost centrelock
Spokes: Black stainless
Tyres: Maxxis Rekon 2.8″ with Kevlar bead Front – Maxxis Rekon 2.8″ with Kevlar bead Rear
Seatpost: Merida Expert Dropper 30.9mm
Pedals: XC pro alloy
Occasionally without notice, manufacturers sometimes change product specifications
