Yeastar Neogate VoIP GSM Gateway

Yeastar TG Series VoIP GSM Gateways connect GSM or WCDMA or 4G LTE to VoIP networks to provide two-way communication: GSM/3G/4G to VoIP and VoIP to GSM/3G/4G. This allows you to connect most IP-based telephone systems including Yeastar IP Phone Systems, and softswitches to a GSM or 3G WCDMA or 4G LTE; which can provide a sophisticated fallback solution when landlines go down, or be used to increase call traffic capacity by providing additional dial-tone.

► GSM Voice Calls
► VoLTE for HD Calls
► Maximum Cost Reduction
► Top Quality and Reliability
► Mobile Connectivity for SMB

Easy to use

Easy to use

Simple and intuitive Web-based
configuration saves you loads
of time

mobile trunking

Mobile Trunkings

Add GSM/WCDMA trunkings for
business making high number of
calls to mobile networks

SMS Service

Bulk SMS Service

Great tool for enterprises to
manage customer relations and
introduce special offers
with a low cost

Interoperability

Interoperability

Interoperable with a broad list
of softswitch, PBX, and IP-PBX
like Elastix and Lync Server

Models* TG100 TG200 TG400 TG800 TG1600
Number of Ports 1 2 4 8 16
GSM Frequency** 850/900/1800/1900 MHz
WCDMA Frequency** 850/1900 MHz, 850/2100 MHz, 900/2100 MHz
4G Data –
4G LTE Band** Don’t support 4G LTE Depending on the module type. The supported band and operators can be found here.
Protocol SIP, IAX2
Antenna Splitter (4 in 1) – Support
Transport UDP, TCP, TLS, SRTP
Voice Codec G.711 (alaw/ulaw), G.722, G.726, G.729A, GSM, ADPCM, Speex
DTMF Mode RFC2833, SIP Info, In-band
Echo Cancellation ITU-T G.168 LEC
Calling Type Termination (VoIP to GSM/WCDMA), Origination (GSM/WCDMA to VoIP)
Console Port – 1
Network Protocol FTP, TFTP, HTTP, SSH
LAN 1 10/100 Mbps Ethernet Interface 2 10/100 Mbps Ethernet Interfaces
NAT Traversal Static NAT, STUN
Network DHCP, DDNS, Firewall, OpenVPN, Static IP, QoS, Static Route, VLAN
Operation Range 0°C to 40°C, 32°F to 104°F
Power Supply DC 12V, 1A AC 100-240V
Storage Range -20°C to 65°C, -4°F to 149°F
Dimensions (L × W × H) (mm) 110 x 70 x 24 213 x 160 x 44 340 x 210 x 44 440 x 250 x 44
Humidity 10-90% non-condensing

*You could order either GSM or 3G or 4G channel. TG100 does not support 4G LTE.
**Click here to check the frequency/band and cellular operators supported by TG GSM VoIP Gateway.
