Construction(DUAL)

Center Conductor:

1.02±0.01mm Solid Copper/Copper Clad Steel

Dielectric:

4.57+0.05mmFoam PE

Shield:

Bonded Al Foil

Braid Coverage:

50-90%Al

Jacket:

6.90+0.10mmPVC

Jelly/APD

Per Customers’ Special Requirement

Characteristics

Sparker Test:

4000VAC

Impedance:

75+3 Ohm

Capacitance:

54+3pF/m

Velocity of Propagation:

82% (min)

Return Loss:

20dB min (5-2300MHz)
