Launch X-931 Touchless Wheel Aligner
1. Measurement Parameters
| Alignment Parameters | Measurement Range |
| Total Toe-in | ±20︒ |
| Individual Toe-in | ±10︒ |
| Camber | ±10︒ |
| Caster | ±20︒ |
| Kingpin inclination | ±20︒ |
| Thrust Angle | ±5︒ |
2.Equipment Parameters
| Technical Index | Description |
| Wheelbase | For passenger vehicle and light commercial vehicle, from 1800mm to 3750mm |
| Input Voltage | 100～220V AC (10A) |
| Input Frequency | 50～60Hz |
| Power | 0.5KW |
| Others | Computer host, LCD display, keyboard & mouse; Measurement software; Printer and loudspeaker, etc. |
