Engine Type

4-Stroke Twin Cylinder

Displacement

760cc High Output (H.O.)

Fuel System

Electronic Fuel Injection

Transmission/Final Drive

Automatic PVT P/R/N/L/H; Shaft

Drive System

On-Demand True AWD/2WD

Shocks

Dual A-Arm with Anti-Sway Bar 9″ (22.9 cm) Travel in the Front and 9.5″ (24 cm) Travel in the Rear

Suspension Springs

Standard

Front Suspension

Dual A-Arm with Anti-Sway Bar 9″ (22.9 cm) Travel

Rear Suspension

Dual A-Arm, Rolled with Anti-Sway Bar 9.5″ (24 cm) Travel

Front/Rear Brakes

4-Wheel Hydraulic Disc with Dual-Bore Front Calipers

Parking Brake

Park in Transmission

Front Tires

25 x 8-12; Ancla

Rear Tires

25 x 10-12; Ancla

Wheels

Stamped Steel

Wheelbase

77″ (196 cm)

Dry Weight

993 lb. (450 kg)

Overall Vehicle Size (L x W x H)

103 x 50 x 69″ (261.6 x 127 x 175.2 cm)

Ground Clearance

10.6″ (26.9 cm)*

Fuel Capacity

7.25 gal (27.4 L)

Bed Box Dimensions (L x W x H)

22 x 42 x 10″ (56 x 107 x 25 cm)

Front/Rear Rack or Box Capacity

N.A./300 lb (136.1 kg)

Payload Capacity

740 lb (335.6 kg)

Hitch Towing Rating

1,500 lb (680.4 kg)

Hitch/Type

Standard/1.25″ Receiver

Cooling System

Liquid

Seat Type

Standard

Cargo System

Lock & Ride

Lighting

Halogen, 55W low/ 60W high

Electronic Power Steering

Available on Limited Edition

Instrumentation

Digital Gauge, Speedometer, Odometer, Tripmeter, Tachometer, Coolant Temperature, Volt Meter, Hour Meter, Service Indicator, Clock, Gear Indicator, Fuel Gauge, Hi-Temp Light, Seatbelt Reminder Light, DC Outlet

Bodywork

Standard
